Method predicts asymmetrical edges of 2D crystals

A new method can predict the shapes of asymmetrical crystals.

A crystal’s shape is determined by its inherent chemistry, a characteristic that ultimately determines its final form from the most basic of details. But sometimes the lack of symmetry in a crystal makes the surface energies of its facets unknowable, confounding any theoretical prediction of its shape.

Theorists say they’ve found a way around this conundrum by assigning arbitrary latent energies to its surfaces or, in the case of two-dimensional materials, its edges.

In the same way a magician finds a select card in a deck by narrowing the possibilities, a little algebraic sleight-of-hand goes a long way to solve the problem of predicting a crystal’s shape.

The method described in Nature Computational Science shows using what they call auxiliary edge energies can bring predictions back in line with the Wulff construction, a geometrical recipe in use for more than a century to determine how crystals arrive at their final equilibrium shapes.

The open-access paper by materials physicist Boris Yakobson, lead author and alumnus Luqing Wang, and their colleagues at Rice’s George R. Brown School of Engineering introduces algorithms that employ arbitrary numbers for the right-hand factors in the equations and still deliver the proper unique shape-solution.

“The issue of shape is compelling, but researchers have been trying and failing for years to compute surface energies for asymmetrical crystals,” Yakobson says. “It turns out we were falling down a rabbit hole, but we knew that if nature can find a solution through a gazillion atomic movements, there should also be a way for us to determine it.”

He says the rise of interest in 2D materials in recent times motivated the new study. “We had a ‘eureka’ moment: After switching our geometrical thinking to algebraic we added closure equations that contain arbitrary parameters,” Yakobson says. “These seem unhelpful, but we passed it all through the computer and observed a well-defined shape coming out,” he says.

“The hard part was convincing our reviewers that edge energy is truly undefinable, but a solution can still be achieved,” Wang says.

The work could provide a valuable tool to researchers who grow crystals from the bottom up for catalytic, light-emitting, sensing, magnetic, and plasmonic applications, especially when their shapes and active edges are of particular importance.

The researchers point out that natural crystals enjoy the luxury of geological time. They arrive at their shapes by “relentlessly performing a trial-and-error experiment” as they seek equilibrium, the minimal energy of all their constituent atoms.

But computational and theoretical approaches simply can’t deal with billions of atoms at once, so they generally lean on the energies of outward-facing atoms. For many crystals that have equivalent facets or edges, that works just fine.

In 2D materials, essentially all of the atoms are “outward-facing.” When their edges are equivalent by symmetry—in rectangles, for instance—completing a Wulff construction is simple after calculating the edge energies via density functional theory.

But in the absence of symmetry, when all the edges are different, the calculated average energy is meaningless, Yakobson says.

“Nature has the answer to shape a crystal regardless of what it ‘knows’ or doesn’t about the edge energies,” he says. “So there is an answer. Our challenge was to mimic it with theory.”

The first step toward a solution was to consciously give up on finding the unknowable absolute edge energies and deal instead with their well-defined computable combinations, Yakobson says. Geometrically, this was quite a riddle, and for asymmetric bulk materials was hopelessly complicated.

“But 2D materials and their planar polygons made solving the problem easier to think about than having to deal with multifaceted polyhedra,” he says.

Finding and establishing average energies was just the first step, followed by “closure equations” that used arbitrary latent material energy for the right-hand side of the equation. Even if the latter numbers were intentionally incorrect, applying all to the textbook Wulff construction resulted in the correct crystal shape.

The group tested its theory on several 2D crystals and compared the results to the crystals’ observed final forms. Their versatile equations successfully predicted the shapes, shown experimentally, of the truncated rectangle formed by 2D tin selenide, a promising thermo- and piezoelectric material, and the asymmetric needles formed by silver nitrite.

The work was primarily supported by the Department of Energy and the Basic Energy Sciences program and in part by the Army Research Office Electronics Division.

Source: Rice University
